Dual WAN
|
● Dual Gigabit Ethernet Ports
● Failover
● Load balancing
|
|
Standards
|
● 802.3, 802.3u
|
|
WAN connectivity
|
● Dynamic Host Configuration Protocol (DHCP) server, DHCP client, DHCP relay agent
● Point-to-Point Protocol over Ethernet (PPPoE) ● Point-to-Point Tunneling Protocol (PPTP) ● DNS relay, Dynamic DNS (DynDNS, 3322) |
|
Routing protocols
|
● Static
● Routing Information Protocol (RIP) v1, v2, and RIP for IPv6 (RIPng) |
|
Network Address Translation (NAT)
|
● Port Address Translation (PAT)
● One-to-one NAT
● NAT traversal
|
|
Protocol binding
|
Protocols can be bound to a specific WAN port for load balancing
|
|
Network edge (DMZ)
|
DMZ port
DMZ host
|
|
Dual USB ports
|
3G/4G modem support
|
|
Security
|
|
Firewall
|
● Denial of service (DoS), ping of death, SYN flood, land attack, IP spoofing, email alert for hacker attack
|
|
Access rules
|
● Schedule-based access rules ● Up to 50 entries
|
|
Port forwarding
|
Up to 30 entries
|
|
Port triggering
|
Up to 30 entries
|
|
Blocking
|
Java, cookies, ActiveX, HTTP proxy
|
|
Secure management
|
● HTTPS web access to device manager ● Username/password complexity enforcement
|
|
VLAN
|
802.1Q VLAN
RV320: 7 VLANs supported
RV325: 17 VLANs supported
|
|
VPN
|
|
IP Security (IPsec)
|
● 25 IPsec site-to-site tunnels for branch office connectivity ● 25 IPsec VPN tunnels via Cisco VPN client and third-party clients such as “TheGreenBow” for remote access VPN connectivity
|
|
SSL VPN
|
10 SSL VPN tunnels for remote client access
|
|
PPTP
|
10 PPTP tunnels for remote access
|
|
Encryption
|
● Data Encryption Standard (DES) ● Triple Data Encryption Standard (3DES)
● Advanced Encryption Standard (AES) encryption: AES-128, AES-192, AES-256
|
|
Authentication
|
MD5/SHA1 authentication
|
|
IPsec NAT traversal
|
Supported for gateway-to-gateway and client-to-gateway tunnels
|
|
VPN pass-through
|
PPTP, Layer 2 Tunneling Protocol (L2TP), IPsec
|
|
Advanced VPN
|
● Dead peer detection (DPD) ● Split DNS
● VPN backup
● Internet Key Exchange (IKE) with certificate
|
|
Quality of Service (QoS)
|
|
Prioritization types
|
Application-based priority on WAN port
|
|
Service-based QoS
|
Supports rate control or priority
|
|
Rate control
|
Upstream/downstream bandwidth can be configured per service
|
|
Priority
|
Each service can be mapped to one of 3 priority levels
|
|
Performance
|
|
IPsec VPN throughput
|
100 Mbps
|
|
SSL VPN throughput
|
20 Mbps
|
|
Concurrent connections
|
RV320: 20,000
RV325: 40,000
|
|
Configuration
|
|
Web user interface
|
Simple browser-based device manager (HTTP/HTTPS)
|
|
Management
|
|
Management protocols
|
● Web browser (HTTP/HTTPS) ● Simple Network Management Protocol (SNMP) v1, v2c, and v3
● Bonjour
|
|
Event logging
|
● Syslog
● Email alert
● Short Message Service (SMS)
|
|
Upgradability
|
● Firmware upgradable through web browser ● Imported/exported configuration file
|
